LC MINI 250

Hydraulic platform - indistinguishable from lift

 Example of solution





Technical specifications LC mini 250

  • Load capacity 250 kg
  • Number of persons 3
  • Travel max 12 m
  • Cabin 650x800 mm
  • Shaft 1000x950 mm
  • Shaft head 2500 mm
  • Pit min. 200 mm
  • Frame Type RVD2
  • Hydraulic drive
  • Engine power 1,8kW - 2,2 kW
  • Door width 600 - 800 mm
  • Klefer semiautomatic doors
  • Automatic doors







Files for download

  • Construction preparation for LC MINI 250 - 500 - Download
  • LC MINI 250, shaft 1000x950 - Download
  • LC MINI 250, shaft 1100x1000 - Download
  • LC MINI 250, shaft 1200x1050 - Download
  • LC MINI 250, shaft 1300x1150 - Download
  • LC MINI 250, shaft 1300x1250 - Download
  • LC MINI 250, shaft 1300x1350 - Download
  • LC mini 250, rear technology - Download

Offered lift cars



Sample of surfaces for LC Classic cabin

Sample of surfaces for LC Elegant and Exclusive cabin
